BenQ TH685P vs JVC DLA-NP5
What TH685P does better (3) and where DLA-NP5 wins (4) — every spec side by side.
Dimensions
Size comparison
TH685PDLA-NP5
| TH685P | DLA-NP5 | Difference | |
|---|---|---|---|
| Height | 110 mm | 234 mm | −124 mm |
| Width | 312 mm | 500 mm | −188 mm |
| Depth | 225 mm | 495 mm | −270 mm |
| Weight | 2.8 kg | 19.2 kg | −16.4 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is TH685P better than DLA-NP5?
- Weight2.8 kg vs 19.2 kg6.9×
- Audio outputYes · DLA-NP5: No
- Largest image size300″ vs 200″+50%
Why is DLA-NP5 better than TH685P?
- Resolution (on screen)1920 × 1080 (Full HD) vs 4096 × 2160 (DCI 4K)
- Native panel resolution1920 × 1080 (Full HD) vs 4096 × 2160 (DCI 4K)
- HDMI inputs1 vs 22×
- Ethernet (LAN)No · TH685P: Yes
Specifications
Side by side
| Picture | ||
| Resolution (on screen) | 1920 × 1080 (Full HD) | 4096 × 2160 (DCI 4K) |
| Native panel resolution | 1920 × 1080 (Full HD) | 4096 × 2160 (DCI 4K) |
| 4K method | — | Native 4K |
| Display technology | DLP | LCoS (SXRD / D-ILA) |
| Light source | Lamp | — |
| Brightness (ANSI / ISO lumens) | — | 1,900 lm |
| Contrast ratio (dynamic / claimed) | — | 40,000:1 |
| HDR support | — | Yes |
| HDR formats | — | HDR10, HLG |
| Gaming | ||
| Maximum refresh rate | 120 Hz | 120 Hz |
| Lens & placement | ||
| Throw ratio | 1.13:1 | — |
| Throw ratio (zoomed in) | 1.46:1 | — |
| Throw type | Standard throw (1.0:1 and longer) | — |
| Distance for a 100″ 16:9 image | 2.5 m | — |
| Smallest image size | 30″ | 60″ |
| Largest image size | 300″ | 200″ |
| Lens shift | — | Vertical and horizontal |
| Sound | ||
| Built-in speakers (total output) | 5 W | — |
| Connectivity | ||
| HDMI inputs | 1 | 2 |
| USB-C video input | Yes | — |
| USB port | Yes | Yes |
| Ethernet (LAN) | No | Yes |
| VGA input | Yes | No |
| Audio output | Yes | No |
| Battery, power & lifetime | ||
| Power consumption | — | 420 W |
| Light source life | 4,000 h | — |
| Light source life (eco mode) | 10,000 h | — |
| Design & noise | ||
| Fan noise | 35 dB | — |
| Fan noise (eco mode) | 29 dB | 24 dB |
| Weight | 2.8 kg | 19.2 kg |
| Width | 312 mm | 500 mm |
| Height | 110 mm | 234 mm |
| Depth | 225 mm | 495 mm |
| Colours | White | — |
